Fluorescent protein microscope

Fluorescent protein microscope

Brand ：Thmorgan
Model ：DFP

A product features:

1. Detection of green fluorescent protein (GFP) and red fluorescent protein (DsRed);

2. Easy for field work;

3. High detection efficiency: Find positive targets in the field at night, at a glance;

4. Easy to operate: small, flexible, easy to carry, no heat engine after starting, direct detection;

5. System stability: it can work continuously for a long time;

6. Safety: No chemical substrate color, direct observation, no damage to the cells of the tested object.



Two product uses:

1. Detect green fluorescent protein (GFP) gene, red fluorescent protein (DsRed) gene of plants: rice, wheat, corn, soybean, cotton, Arabidopsis, etc.;

2. Detection of GFP, DsRed gene transfer animals: mice, rabbits, monkeys, etc.;

3. Detect microorganisms transferring GFP and DsRed genes: bacteria, fungi, yeast, etc.;

4. The tissue-specific expressions of GFP and DsRed genes were detected.

Three working principles:

The blue light source irradiated green fluorescent protein (GFP) and stimulated green fluorescence. Red fluorescent protein (DsRed) was stimulated by green light source. The filter blocks all the reflected light, allowing only the corresponding fluorescence to pass through.



Four technical parameters:

1. Excitation light source: blue, green double excitation light;

Blue excitation light source wavelength range: 445-488 nm;

Green excitation light source wavelength range: 520-532 nm;

2. Filter system: the filter blocks all reflected light and only allows the corresponding fluorescence to pass through;

Yellow glasses filter can detect wavelength range: > 488nm; The specific test diagram is as follows:

Red glasses filter can detect wavelength range: > 580nm; The specific test diagram is as follows:

3.LED life: >10,000 h;

4. Light source type: 2 high-intensity 3W LED;

5. Duration: >4 h;

6. Volume: 12.7cm (l) × 7.6cm (d);

7. Power supply: 6V



Five configurations:

Excitation light source: one

Filters: two

Fluorescent protein microscope
